Descrizione
Audio :Input 3.5 mm
Output: HDMI, Ethernet, SDI
Dimensions (H × W × D): 150 mm × 181 mm × 116 mm
Weight: 1.38 kg (3.04 lbs)
Camera Sensor: 1080P FHD
Resolution: 1080p, 720p, SD @ 30 fps
Field of view
Horizontal: 55°
Vertical: 31°
Diagonal: 63°
Vertical: 31°
Diagonal: 63°
Zoom: Optical: 20x Digital: 10x
Pan | Tilt: ±170° | -30° to 90°
Pan | Tilt speed: 100°/sec | 45°/sec
Focus: Auto and manual
Preset positions
Remote: 10
LAN: 255
LAN: 255
Lens type
Glass
Low light performance 0.5 Lux
Video Output:
USB 3.0, HDMI, Ethernet, SDI
Ethernet
RJ-45
1GbE port, Power over Ethernet
Control interface
In | Out
RS232, RS422, RS485 | RS232
Compatibility
Operating systems
Windows 7 (1080P/720P), Windows 8.1, Windows 10, macOS™ 10.10, Linux (UVC), and later
BenQ Displays
CP01K, CS01, SL02K, ST02, RP02, RM02K, RM02S, RE01, RP01K, ST01K, and later models
USB
Plug and play
Package Contents
Included
• 1080P FHD PTZ conference cam
• Remote control
• Camera mount (built-in)
• USB 3.0 Type-B
• Power supply
• Remote control
• Camera mount (built-in)
• USB 3.0 Type-B
• Power supply
